This series of machine broke materials through the high-speed rotating hammer body and collision the material surfaceit has a simple structure, large crushing ratio, high production efficiency and other characteristicsit can be used for dry and wet two forms crushingit applies to mining, cement, coal, metallurgy, building materials, roads, fire and other departments chronology medium hardness and brittle materials. The device can change material particle size and adjust gap of article grate in accordance with user requirements, so it can meet different users demand.
Characteristics of Ring Hammer Crusher:
This ring hammer crusher has simple structureConvenient operation and maintenancebest-selling both in domestic and abroadwell received by users.
Main Purpose of Ring hammer crusher
Ring hammer crusher for crushing all kinds of hard and abrasive weak materials. The material compressive strength does not exceed of 100Mpa, Moisture content is less than 15%. Broken material is coal, salt, chalk, gypsum, brick, limestone etc. it also can broke fiber structuremore flexibility and toughness of the broken woodpaperwaste of asbestos cementrecycling of asbestos fibers and so on. Besides, Hammer crusher can be used not only in broken production linesand production line systembut also can replace the cone crusher in the mineral processing production line.
The main working parts of ring hammer crusher is the rotor with a hammer (or hammer)rotor is composed of spindle, disk, pin and hammer. The motor drive the rotor with high-speed rotation in the broken cavitymaterials from the up mouth feeder into the machineit is crushed by high-speed movement of the hammer blows impact, shear, grinding. Under the rotor, there is a screening plate, the crushed material whose size is smaller than the sieve can come out through the sieve, and the other material whose size is bigger than the sieve will still be combated and grinded by the hammer, finally through the plate out.

Application of Ring Hammer Crusher :
This series of ring-hammer crushers is suitable for crushing various materials of brittleness such as coal, gangue, coke, slay, shale and loose lime stone etc. Whose compressive resistance does not exceed 10Mpa and the surface moisture content should not be greater than 8%.

Ring Hammer Crusher Series Working Principle :
This series of machine is a punching rotor type crushing machine with ring-hammer on the rotor. First the material fed to the crushing space is crashed by punching force of the ring-hammer rotating at high speed. mean while the material crushed gets kinetic energy from the and is punched forward the crushing board, then it gets punched the second time and fall to the sieve plate. The material is cut, squeezed and crushed into pieces by the force of ring-hammer and their own rubbing and get out of the machine will be sent to the metal collector and get cleared off periodically.
